Hypertherm Powermax45 XP Plasma System, 20' Lead, 200-240 V CSA

Linde Part #: HYP088112 Manufacturer's Part #:088112  /

How do I buy this?
Hypertherm Powermax45 XP Plasma System, 20' Lead, 200-240 V CSA

Standard Power Supply, 75 Degree Hand Torch

The Powermax45 XP plasma cutter delivers increased cut capacity - up to 16 mm (5/8") metal - as well as faster cut speeds, and automatic gas adjustment for quick, simple setup and operation. Duramax Lock torches support handheld and mechanized cutting of a wider range of metal thicknesses, along with precision gouging such as spot weld removal, and marking capabilities.


Easy to Use

  • One of our most compact and light weight systems, the Powermax45 XP is the ideal portable plasma cutter for a 16 mm (5/8") rated cutting system
  • Patented drag-cutting technology makes the Powermax45 XP easy to use - even for first-time operators
  • Smart Sense technology ensures that air pressure is always correctly set

Outstanding Versatility

  • CNC interface and FastConnect torch connection allows both handheld and mechanized operation
  • A wide range of torch and consumable styles to choose from for both handheld and automated processes
  • Extensive array of application capabilities via specialty consumables for fine feature cutting, extended reach cutting, gouging, precision gouging and marking

Maximum Productivity

  • Finish jobs faster, with cut speeds 1.5 times greater than oxyfuel on 6 mm (1/4") mild steel
  • Superior cut and gouge quality reduces time for grinding and edge preparation
  • New torch disable switch feature allows faster, easier changeout of consumables

Rugged and Reliable

  • Duramax Lock torches are designed for high-impact and heat resistance
  • SpringStart technology ensures consistent starting and optimum torch performance
  • Hypertherm Certified reliability ensures peak performance even in the most demanding environments

Designed for Low Environmental Impact

  • Plasma cutting efficiency is 11% better than its predecessor, enabling you to cut more steel with less power, in less time
  • All plasma system components are recyclable
  • 14% lighter than its predecessor and delivers more cutting power
Brand Hypertherm
Duty Cycle 50% at 45 A
Frequency 50 Hz, 60 Hz
Maximum Amperage 39 A
Maximum Cutting Thickness 7/8 in
Minimum Amperage 32 A
Minimum Cutting Thickness 5/8 in
Output Current 10 - 45 A
Voltage 200 - 240 V
MFG 088112
Subcategory Cutting Equipment
UNSPSC 23241506
